Beauty in simplicity
SlimWall 35 is a slender stick façade system that combines elegant aesthetics with Passive House certified performance up to two floors high. Create wide-open views that last a lifetime.
|
Techninės charakteristikos
|
| Max. dimensions & weight: |
|
| Max. weight of glass |
450 kg |
| Min. intertia mullion - Ix |
76.961 cm4 |
| Max. intertia mullion - Ix |
572.545 cm4 |
| Min. intertia transom - Ix |
70.5 cm4 |
| Max. intertia transom - Ix |
545.812 cm4 |
| Min. intertia transom - Iy (glass load) |
13.309 cm4 |
| Max. intertia transom - Iy (glass load) |
30.308 cm4 |
| Sightlines: |
|
| Min. width transom profile |
35 mm |
| Min. visible width (interior view) |
35 mm |
| Min. visible width (exterior view) |
35 mm |
| Min. depth mullion |
89 mm |
| Max. depth mullion |
194 mm |
| Min. depth transom |
88.5 mm |
| Max. depth transom |
193.5 mm |
| Glazing: |
|
| Rebate height |
10 mm |
| Glazing method |
Siliconized glazing |
| Min. glass thickness - frame/element |
24 mm |
| Max. glass thickness - frame/element |
57 mm |
| Min. glass thickness - vent |
24 mm |
| Max. glass thickness - vent |
57 mm |
